Description
TX12 Pro V2.0 is a dual-band Gigabit Wi-Fi 6 wireless router designed for users who pursue performance experience. Both dual-bands support Wi-Fi 6 (802.11ax) technology and the concurrent rate is up to 2976Mbps (5GHz:2402Mbps, 2.4GHz: 574Mbps). TX12 Pro V2.0 is equipped with a 12nm process dual-core 1.3GHz CPU to ensure a stable and smooth network environment; supports Wi-Fi+, which can easily solve the problem of stable Wi-Fi coverage in very large homes; equipped with 5 built-in high-power FEMs , Wi-Fi has stronger wall penetration capabilities and longer transmission distances; it uses OFDMA+MU-MIMO technology to allow more devices to access the Internet at the same time, significantly improving transmission efficiency and significantly reducing latency.
Highlights:
- Dual-Core Processor, Smooth Network
- Stronger Wi-Fi Signal Throughout Your Home
- Smooth Internet Experience with AX3000
- Ultra-wide Coverage with Wi-Fi+
- Rich Functions，Easy to Master
Ultra Speed with Powerful 5GHz Band
The 5GHz single-band wireless theoretical rate is equivalent to the sum of three AC1200 routers, truly running at full Gigabit bandwidth, allowing you to smoothly experience applications such as short videos, 4K audio and video, online games, live broadcasts and large file downloads.
*The data comparison comes from Tenda Labs and is a theoretical comparison between AX3000 and AC1200 in the 5GHz band.
Dual-Core Processor, Smooth Network
TX12 Pro V2.0 is equipped with a 1.3GHz dual-core CPU, which uses an advanced 12nm process. Its comprehensive computing power is 30% higher than that of the old dual-core AX3000 router. This makes the router consume less power and generate less heat, and its strength ensures a stable and smooth network.
360° Full Signal Coverage
TX12 Pro V2.0 has five external 6dBi high-gain omnidirectional antennas, 3 transmitters and 3 receivers in the 5GHz frequency band, which greatly improves the signal strength in high-speed frequency bands, effectively eliminates side signal blind spots, truly achieves 360° full signal coverage, and provides a better networking experience.
More Enjoyable with Multiplayer
Using OFDMA+MU-MIMO technology, more devices can access the Internet at the same time, the transmission efficiency is significantly improved, the delay is greatly reduced, and multi-player games will not stutter.
Full Gigabit Ports for High Traffic
Supports broadband access within 1000M to meet broadband upgrade needs in the next 2-3 years. Achieve faster and more stable data transmission through LAN port connection, making full use of every megabit of the operator's bandwidth.
Specifications:
- Standard & Protocol: IEEE802.3, IEEE802.3u, IEEE802.3ab
- CPU: Dual-Core 1.3GHz CPU
- RAM: 256MB
- Interface:
- 1× Gigabit WAN Port
- 3× Gigabit LAN Ports
- Antenna: 5*6dbi external antennas
- Button:
- 1*WPS/Mesh button
- 1*Reset button
-
Power:
- Input: AC 100-240V~50/60H
- Output: DC 12V 1A
- LED indicator: 1* LED
- Dimensions: (L*W*H)267*166*222 mm
- Wireless Standards:
- IEEE 802.11ax/ac/n/a 5 GHz
- IEEE 802.11ax/n/b/g 2.4 GHz
-
Data Rate:
- 5GHz: 2402 Mbps (802.11ax, HE160)
- 2.4GHz: 574 Mbps (802.11ax)
-
Basic Functions:
- SSID broadcasting and hiding
- MU-MIMO
- Beamforming signal directional transmission technology
- 160MHz
- OFDMA
- 1024-QAM
-
Wireless Security:
- WPA2-PSK
- WPA3-SAE/WPA2-PSK
- Wireless Security: Enable/Disable
- WPS (WiFi Protected Set-up) fast encryption
-
Internet Connection Type:
- PPPoE, Dynamic IP, Static IP
- PPPoE(Russia), PPTP(Russia), L2TP(Russia)
- Unify, Maxis, Maxis-special, Celcom, Digi
- Network Protocol: IPv4&IPv6
-
Operating Mode: Router Mode; AP Mode; Universal Repeater Mode (Client+AP, WISP）
-
Parental Control: Client Filter; URL Filter; Time Limit
-
DHCP:
- DHCP Server
- DHCP Client List
- DHCP Static IP Address Reservation and Allocation
- Virtual Server: Port Forwarding, DMZ Host, UPnP
-
Firewall:
- ICMP Flood Attack Defense
- TCP Flood Attack Defense
- UDP Flood Attack Defense
- Block Ping From WAN
- DDNS: DynDNS, no-ip, oray, 88ip
-
VPN:
- IPSec Transparent Transmission
- PPTP Transparent Transmission
- L2TP Transparent Transmission
- PPTP VPN Server
- PPTP VPN Client
- L2TP VPN Client
-
Special Features:
- Wi-Fi+(Mesh System)
- Smart diagnosis
- IPTV IPv6
- Smart LED on/off
-
Other Function:
- Support App and web management
- Bandwidth Control
- Guest Network
- MAC Address Clone
- Supports blacklist and whitelist
- Unify 2.4 GHz & 5 GHz
- Static Routing
- Remote Web Management
- Backup & Restore configurations
- Firmware upgrade online
-
Temperature:
- Operating Temperature: 0℃~40℃
- Storage Temperature: -40C ~70℃
-
Humidity:
- Operating Humidity: 10 %~90% RH non-condensing
- Storage Humidity: 5 %~ 90%RH non-condensing
-
Package Content:
- Wi-Fi Router *1
- RJ45 Ethernet Cable*1
- Power Adapter*1
- Quick Installation Guide*1
